Low consumption industrial grade nb iot remote terminal unit rtu

Short Description:

CoAP/China Telecom NB-IoT Cloud/Industrial Grade Workmanship/Low Power Consumption/DI&DO


Product Detail

Product Tags

Overview
Quick Details
Chipset:
BC95
Model Number:
MDNR311
Application:
Industry data transmission terminal
Brand Name:
MIND
Place of Origin:
Sichuan, China
Product name:
nb iot industrial grade data transmission terminal DTU
Type:
remote terminal unit
Serial data interface:
RS232/RS485 TTL
Network:
NB-IOT UL/DL:200kbps/200kbps
Frequency Band:
MDN311-BX:international version
Working Temperature:
-30℃ ~ +75℃
SIM Card:
standard si:3V
Physical characteristics:
10.5cm * 6cm * 2.2cm
Relay output:
Tow-channel relay output
Supply Ability
Supply Ability:
10000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Low consumption industrial grade nb iot remote terminal unit rtu1 set/bag (with customized parts)
Port
Chengdu/shanghai/shenzhen
Lead Time :
Quantity(Sets) 1 – 100 >100
Est. Time(days) 7 To be negotiated

Industrial Grade NB-IoT RTU

CoAP/China Telecom NB-IoT Cloud/Industrial Grade Workmanship/Low Power Consumption/DI&DO

Power Failure Warning

In the event of a sudden power failure, the backup power supply will be activated and a power failure warning will be sent automatically, allowing users to know the status of the equipment in real time.

Independent R&D-Support script programming

  • MDNR311 supports script programming. Users can customize scripts. There is no need for additional controllers and no need to rely on the platform to issue collection instructions. Directly connected meters can actively collect data from the meters and report them to the platform.
  • The maximum collection volume can reach more than 50 instruments and meters, greatly reducing hardware costs.
  • The reporting logic of DI (digital acquisition) can be customized in the script file.
  • The control logic of DO (relay output) can be customized in the script file.

PSM Low Power Mode

The device runs with low power consumption and can’t receive downlink data from the data center. The RTU must actively upload data and enter the connection mode before the center can send data. After no data communication, MDNR311 RTU automatically enters PSM mode to maintain low power consumption standby.

SMS Push

The device can connect to the mobile phone through the Mind IoT cloud, and push data messages to the mobile phone in time. It supports sending to multiple mobile phones at the same time. Please contact online customers for consultation.

Heartbeat Packet Mode

By continuously sending data to connect to the server normally, the device is in an active state, ensuring the normal operation of device communication.

Software&Hardware Dual Watchdog

Adopting the hardware solution of “communication brand module + external independent 32-bit ARM core CPU”

  • Well-designed external watchdog circuit, stable operation without crash, suitable for various field environment applications
  • Integrated high-reliability composite watchdog, dual-dog soft/hard mode is mutual backup, DTU does not go down, to ensure the stability of data transmission

Support local/remote configuration upgrade

The user does not need to upgrade the firmware/software on the device site, and can remotely operate the device firmware/software upgrade through the monitoring center, saving manpower. The upgrade interface is fully graphical operation, unified with the local upgrade operation interface, and the device can operate normally during the remote upgrade process.

Technical Parameters



Characteristics Descriptions
Power supply VIN interface: DC5V-30V
BAT interface: DC3.5V-4.2V
Power consumption Regular version:VIN interface, DC12V Power Supply
Online Mode Current:60mA-150mA
Peaking working Currentt:500mA
PSM/IDLE Mode Current:≈13mA
Low power version: BAT interface, 3.7V Lithium battery Power Supply
Online Mode Current:60mA-150mA
Peaking working Currentt:500mA
PSM/IDLE Mode Current:≈20uA
Frequency Band MDN311-B5: China Telecom 850M
MDN311-B8: China Mobile/Unicom 900M
MDN311-Bx: International version
Network NB-IoT UL/DL:200kbps/200kbps
SIM Card Micro SIM:3V
Antenna Connector SMA connector-external thread inner hole
Series Data interface RS232,RS485 Level
Baud Rate:1200-38400bps
Data bits: 8
Parity check:No
Stop bits:1bits
Temperature range Working environment temperature: -30°C to +75°C
Storage temperature -40°C to +85°C
Humidity range Relative humidity 95% (no condensation)
Physical characteristics length: 10.5cm, width: 6cm, height: 2.2cm
